Journeyman® 360 OIL Indirect-Fired Heater

JOURNEYMAN® 360 OIL INDIRECT-FIRED PORTABLE HEATER

BTU/HR: 360,000

Foreman 230 Oil Fuel Type: #1 or #2 Fuel Oil/Diesel

The Journeyman® 360 Oil indirect fired portable heater provides trimmed and simplified raw heat to your worksite at a very competitive price. Indirect fired technology exhausts combustion outside of heated environment while providing the ability to duct heat up to 25 feet. Operates from diesel #1 or #2, indoor/outdoor rated, and produces 360,000 BTU per hour. Onboard 40-gallon fuel tank. Equipped to move manually. Manufactured in Wisconsin. Buy this certified portable heater with confidence – L.B. White backs your purchase with a 2-year warranty and free lifetime of technical support.

Heat Estimator

Buy Now

FEATURES

360,000 btu/hr

2,000 CFM

Diesel #1 and #2

SPECS

JOURNEYMAN	360 OIL
BTU/HR Rating	360,000
Blower Fan Output (CFM)	2,000
Fuel Type	DIESEL #1 OR #2
Fuel Consumption Max	2.6
Burner Type	Beckett
Outlet Static Pressure (in. W.C.)	0.7 (two 12” outlets) / 0.5 (one 16” outlet)
Motor Horsepower	1/2
Electrical Supply (volts/hz/phase)	120/60/1
Amps (start/continuous)	8
L x W x H (in.)	71.75 x 33.5 x 50.5
Ship Weight (lbs)	457
Outlet Duct Diameter (in.)	12” (for two ducts - S) / 16” (for one duct - O)
Outlet Duct Connections	2
Outlet Duct Max Length (ft.)	25
Air Recirculation Inlet Dia. (in.)	n/a
U.S./Canadian Certification	Yes
